Product Introduction
2 Stroke 15HP outboard motor (6B4) Model
Specification
| Model | E15DMS | E15DML |
| Engine type | In-line 2 | In-line 2 |
| Fuel Induction System | Carburetor | Carburetor |
| Displacement | 246cc | 246cc |
| Bore*Stroke | 56*50mm | 56*50mm |
| Gear Ratio | 27:13 | 27:13 |
| Max.rpm Range | 4500~5500 | 4500~5500 |
| Max.Prop Shaft Output | 11.0KW(15CV) | 11.0KW(15CV) |
| Alternator output | 11Volt 6Amps. | 11Volt 6Amps. |
| Engine Transom Heigt(mm) | 441mm,(17.4in) | 568mm,(22.4in) |
| Dry Weight(Kg.) | S: 38Kg | L: 40Kg |
| Starting System | Manual | Manual |
| Control System | Tiller control | Tiller control |
| Trim&Tilt | Manual Tilt | Manual Tilt |
| Built-in Fuel Tank(L) | 24Lts. | 24Lts. |
| Lubrication System | Pre-mixed | Pre-mixed |
| *D=Back control (Tiller control) M=Manual start | ||
| S=Short shaft L= Long shaft |
